One of the tasks Google Earth Pro is really useful is getting a quick idea of the viewshed from a specific location. This is particularly useful for planning solar installations or other infrastructure projects such as LoRaWAN gateway deployments.

Whilst the tool is quite powerful, it has a very limited viewshed (roughly 5km) and this is not really useful when looking at gateway deployments that in flat regions of Australia easily can reach 25km+. Also it is not at all obvious how to modify the radius of the viewshed since that has not been a feature in the GUI and it is not documented at all.

One common task for my Raspberry Pi Zero with (infrared) Camera is to do still image capture in regular intervals and upload the images for storage and post-processing. A simple way to achieve this with standard software tools available in the Raspberry Pi OS repositories is to use the S3 CLI tools and a simple bash script run by a scheduled cron job.

The Siemens IoT2000 series has been a very interesting development from Siemens and it’s really encouraging to see the use of Open Source in the Automation sector definitely on the increase. And that can only be a good thing for developer productivity. Seeing a different IDE for each manufacturer of a PLC invokes some nasty memories of last century web-application development…


Unfortunately, all the documentation for these units still assumes a Windows PC. And since I have not really been using a physical Windows machine for 10+ years now, that is really slowing things down. For the last few I didn’t really have to fall back to a VM, largely due to the fact that in web-development nobody cares about OS any longer. But I have a feeling that shifting my focus to the IIoT space this VM will get a bit more useful as some of these manufacturers don’t even bother with anything but Windows and are challenged enough to keep up with Windows upgrades.

Download existing image

The image can be downloaded from the Siemens support site (if you don’t have an account with Siemens you might have to sign up for a login first. https://support.industry.siemens.com/cs/document/109741799/simatic-iot2000-sd-card-example-image

Turns out that working with PLC equipment you are still fully stuck to Windows. Which means I have to bite the bullet and get an up to date version of a Windows VM running on my machine.

Since I have already paid for my Windows license with my laptop (even though I have never used it) this came in really handy.

<pre class="wp-block-preformatted">sudo apt install acpica-tools
sudo acpidump -n MSDM

This command should dump the Windows key in the bottom right of the output.

After getting rid of my Facebook account a long time ago, finally, I have decided to pull the plug on Twitter as well.

I have become increasingly wary of the changes of the platform as it seeks for a way to monetise it’s user-base. The timeline has increasingly become infested with annoying ads and no way of getting rid of them. Since Twitter effectively killed the whole app ecosystem with their changes to API rules and banning anything that became useful to a substantial number of people.

As the convener for the Adelaide community of The Things Network, I am frequently setting up Multitech Conduit Gateways. Depending on your PC or notebook hardware you might have some problems with the Exar USB-UART driver on Linux.

Here are the steps to getting this unit setup from an Ubuntu (should work for any other Linux distro) machine.

lsusb

Should show something like this:

Bus 002 Device 006: ID 04e2:1410 Exar Corp. XR21V1410 USB-UART IC

Installing VirtualBox is getting increasingly painful on Ubuntu due to the problems with UEFI Secure Boot and the VirtualBox kernel modules. Another reason for an alternative is that running VirtualBox VM’s completely in the background is not as straightforward as it could be.

From the available alternatives I looked into (VMWare, Xen & KVM) it was KVM that fitted my needs (casual VM usage with mostly headless VM’s for testing purposes). Main reasons:

Having just wasted a few hours on getting this Java software running on Linux I am documenting this for future reference and hopefully saving other LoRa / TTN folks some time.

Prerequisites

Install a Java JDK + JavaFX. This should work with the default OpenJDK 8 or 9 which comes as part of the Ubuntu repositories. I ended up installing Oracle JDK 8 as well as I thought the error might be related to OpenJDK.

Install XScreenSaver and remove Gnome default

sudo apt remove gnome-screensaver<br></br>sudo apt install xscreensaver xscreensaver-gl xscreensaver-gl-extra

Run the Screensaver UI and configure

In the “Advanced” section enter your Flickr RSS URL in “Choose Random Image”

https://api.flickr.com/services/feeds/photos_faves.gne?id=YOURFLICKRUSERID #replace with your Flickr User ID

Create a systemd user service to autostart

mkdir -p ~/.config/systemd/user/<br></br>vim ~/.config/systemd/user/xscreensaver.service

Past the following<br></br>[Unit]<br></br>Description=XScreenSaver<br></br>[Service]<br></br>ExecStart=/usr/bin/xscreensaver -nosplash<br></br>[Install]<br></br>WantedBy=default.target

Start and enable systemd user service

systemctl --user enable xscreensaver<br></br>systemctl --user start xscreensaver

I recently purchased a GrovePi Zero and expected this to be a reasonable straight forward way to connect Grove sensors to your Raspberry Pi, read sensor values via Python and pushing them upstream via MQTT. However the software side of things turns out anything but straight forward. Most of the suggestions on the Dexter Industries forum suggest to download some custom OS image – WTF? Hopefully this will save some people time to chase down the same rabbit holes…..

If you are using the GUI (Raspian full download) and want to connect your RPi Zero to a keyboard and monitor there are probably easier ways to do this. These notes are for people that want to use a headless (no monitor and GUI) setup ready to connect to your RPi after first boot via SSH from another terminal.

EDIT [2018-06-05]: I have updated the code with the Firmware 1.18.+ releases. The code is available at our Growing Data Foundation Github.

These notes are to assist Australian IoT enthusiasts to get started in connecting a LoPy to The Things Network as it is unfortunately (not yet) straight forward to make them work with the current AU-915 TTN Channel plans. As the initiator of the local Adelaide Community of The Things Network I have been experimenting with a number of devices to connect sensors to #TTNADL. One of my personal favourites is the Pycom LoPy as a nice middle-ground between capabilities and technical complexity.
